The Metasploit MCP Server (msfmcpd) provides AI applications with secure, structured access to Metasploit Framework data through the Model Context Protocol (MCP). It acts as a middleware layer between AI clients (such as Claude, Cursor, or custom agents) and Metasploit, exposing 8 standardized tools for querying reconnaissance data and searching modules.

This initial implementation is read-only. Only tools that query data (modules, hosts, services, vulnerabilities, etc.) are available. Tools for module execution, session interaction, and database modifications will be added in a future iteration.

Architecture

flowchart TD
    ai_app["AI Application<br>(Claude, Cursor, etc.)"]

    subgraph msfmcp_server["MsfMcp Server"]
        mcp_layer["MCP Layer (8 Tools)<br>Input Validation / Rate Limiting / Response Transformation"]
        rpc_manager["RPC Manager<br>Auto-detect / Auto-start / Lifecycle Management"]
        api_client["Metasploit API Client<br>MessagePack RPC (port 55553) / JSON-RPC (port 8081)<br>Session Management"]

        mcp_layer --> rpc_manager
        rpc_manager --> api_client
    end

    msf["Metasploit Framework<br>(msfrpcd)"]

    ai_app -- "MCP Protocol (stdio or HTTP)<br>JSON-RPC 2.0" --> mcp_layer
    api_client -- "HTTP/HTTPS" --> msf

Quick Start

The simplest way to start the MCP server is with no arguments:

./msfmcpd

The server automatically detects whether a Metasploit RPC server is already running on the configured port. If not, it starts one automatically with randomly generated credentials.

To use specific credentials:

./msfmcpd --user your_username --password your_password

Configuration

Configuration File

Copy the example configuration and edit it:

cp config/mcp_config.yaml.example config/mcp_config.yaml

A MessagePack RPC configuration looks like this:

msf_api:
  type: messagepack
  host: localhost
  port: 55553
  ssl: true
  endpoint: /api/
  user: msfuser
  password: CHANGEME
  auto_start_rpc: true

mcp:
  transport: stdio

rate_limit:
  enabled: true
  requests_per_minute: 60
  burst_size: 10

logging:
  enabled: false
  level: INFO
  log_file: msfmcp.log

For JSON-RPC with bearer token authentication, use the JSON-RPC example instead:

cp config/mcp_config_jsonrpc.yaml.example config/mcp_config.yaml

Command-Line Options

./msfmcpd --help

Options:
  --config PATH                Path to configuration file
  --enable-logging             Enable file logging with sanitization
  --log-file PATH              Log file path (overrides config file)
  --user USER                  MSF API username (for MessagePack auth)
  --password PASS              MSF API password (for MessagePack auth)
  --no-auto-start-rpc          Disable automatic RPC server startup
  -h, --help                   Show this help message
  -v, --version                Show version information

Environment Variable Overrides

All configuration settings can be overridden by environment variables:

Example using environment variables:

MSF_API_HOST=192.168.33.44 ./msfmcpd --config ./config/mcp_config.yaml

Automatic RPC Server Management

When using MessagePack RPC on localhost, the MCP server can automatically manage the Metasploit RPC server lifecycle. This is enabled by default.

How It Works

1. Detection: On startup, the MCP server probes the configured RPC port to check if a server is already running.
2. Auto-start: If no server is detected, it spawns the msfrpcd executable as a child process.
3. Credentials: If no username and password are provided, random credentials are generated automatically and used for both the RPC server and client authentication.
4. Wait: After starting, it polls the port until the RPC server becomes available (timeout: 30 seconds).
5. Shutdown: When the MCP server shuts down (via Ctrl+C or SIGTERM), it cleans up the managed RPC process.

Note: If an RPC server is already running, credentials must be provided via --user/--password, config file, or environment variables to authenticate with it.

Database Support

The auto-started RPC server creates a framework instance with database support enabled by default. If the database is not running when the RPC server starts, a warning is displayed:

[WARNING] Database is not available. Some MCP tools that rely on the database will not work.
[WARNING] Start the database and restart the MCP server to enable full functionality.

Tools that query the database (msf_host_info, msf_service_info, msf_vulnerability_info, msf_note_info, msf_credential_info, msf_loot_info) require a running database. To initialize and start the database:

msfdb init
msfdb start

Then restart the MCP server.

Disabling Auto-Start

Auto-start can be disabled in three ways:

• CLI flag: --no-auto-start-rpc
• Config file: auto_start_rpc: false in the msf_api section
• Environment variable: MSF_AUTO_START_RPC=false

Auto-start is also not available when:

• The API type is json-rpc (requires SSL certificates and a web server)
• The host is a remote address (cannot start a server on a remote machine)

When auto-start is disabled and no RPC server is running, you must start msfrpcd manually:

msfrpcd -U your_username -P your_password -p 55553

MCP Tools

The server exposes 8 tools to AI applications via the MCP protocol.

msf_search_modules

Search for Metasploit modules by keywords, CVE IDs, or module names.

• query (string, required): Search terms (e.g., windows smb, CVE-2017-0144)
• limit (integer, optional): Max results (1-1000, default: 100)
• offset (integer, optional): Pagination offset (default: 0)

msf_module_info

Get detailed information about a specific Metasploit module.

• type (string, required): Module type (exploit, auxiliary, post, payload, encoder, nop)
• name (string, required): Module path (e.g., windows/smb/ms17_010_eternalblue)

Returns complete module details including options, targets, references, and authors.

msf_host_info

Query discovered hosts from the Metasploit database.

• workspace (string, optional): Workspace name (default: default)
• addresses (string, optional): Filter by IP/CIDR (e.g., 192.168.1.0/24)
• only_up (boolean, optional): Only return alive hosts (default: false)
• limit (integer, optional): Max results (1-1000, default: 100)
• offset (integer, optional): Pagination offset (default: 0)

msf_service_info

Query discovered services on hosts.

• workspace (string, optional): Workspace name
• names (string, optional): Filter by service names, comma-separated (e.g., http, ldap,ssh)
• host (string, optional): Filter by host IP
• ports (string, optional): Filter by port or range (e.g., 80,443 or 1-1024)
• protocol (string, optional): Protocol filter (tcp or udp)
• only_up (boolean, optional): Only return running services (default: false)
• limit (integer, optional): Max results (1-1000, default: 100)
• offset (integer, optional): Pagination offset (default: 0)

msf_vulnerability_info

Query discovered vulnerabilities.

• workspace (string, optional): Workspace name
• names (array of strings, optional): Filter by vulnerability names (exact, case-sensitive module names)
• host (string, optional): Filter by host IP
• ports (string, optional): Filter by port or range
• protocol (string, optional): Protocol filter (tcp or udp)
• limit (integer, optional): Max results (1-1000, default: 100)
• offset (integer, optional): Pagination offset (default: 0)

msf_note_info

Query notes stored in the database.

• workspace (string, optional): Workspace name
• type (string, optional): Filter by note type (e.g., ssl.certificate, smb.fingerprint)
• host (string, optional): Filter by host IP
• ports (string, optional): Filter by port or range
• protocol (string, optional): Protocol filter (tcp or udp)
• limit (integer, optional): Max results (1-1000, default: 100)
• offset (integer, optional): Pagination offset (default: 0)

msf_credential_info

Query discovered credentials.

• workspace (string, optional): Workspace name
• limit (integer, optional): Max results (1-1000, default: 100)
• offset (integer, optional): Pagination offset (default: 0)

msf_loot_info

Query collected loot (files, data dumps).

• workspace (string, optional): Workspace name
• limit (integer, optional): Max results (1-1000, default: 100)
• offset (integer, optional): Pagination offset (default: 0)

Integration with AI Applications

Add the MCP server to your AI application configuration. The exact format depends on the client.

Claude Desktop / Cursor

{
  "mcpServers": {
    "metasploit": {
      "command": "/path/to/metasploit-framework/msfmcpd",
      "args": [
        "--config",
        "/path/to/config/mcp_config.yaml"
      ],
      "env": {}
    }
  }
}

Using RVM

If you use RVM to manage Ruby versions, specify the full path to RVM so the correct Ruby and gemset are used:

{
  "mcpServers": {
    "metasploit": {
      "command": "/your/home_dir/.rvm/bin/rvm",
      "args": [
        "in",
        "/path/to/metasploit-framework",
        "do",
        "./msfmcpd",
        "--config",
        "config/mcp_config.yaml"
      ]
    }
  }
}

Security Considerations

Input Validation

All tool parameters are validated against strict JSON schemas. IP addresses are validated using Ruby’s IPAddr class with CIDR support, workspace names are restricted to alphanumeric characters plus underscore/hyphen, port ranges are validated (1-65535), and search queries are limited to 500 characters.

Credential Management

Configuration files should use chmod 600 permissions. Credentials are transmitted securely to the Metasploit Framework API and are never cached or logged by the MCP server.

Rate Limiting

The server applies rate limiting to all MCP tools using a token bucket algorithm. Default: 60 requests per minute with a burst of 10 requests. This is configurable in the rate_limit section of the configuration file.

Logging

Logging is disabled by default. When enabled (via --enable-logging or config), sensitive data (passwords, tokens, API keys) is automatically redacted. Log files should be protected with chmod 600.

Error Handling

Stack traces are never exposed to clients. Error messages are sanitized to avoid leaking credentials. Metasploit API errors are wrapped in the MCP error format.

Testing with MCP Inspector

The MCP Inspector is an interactive developer tool for testing and debugging MCP servers. It runs directly through npx:

npx @modelcontextprotocol/inspector

Troubleshooting

Connection Refused or Timeout

1. Verify the RPC daemon is running: ps aux | grep msfrpcd
2. Check the port is listening: netstat -an | grep 55553
3. Test connectivity: curl -k -v https://localhost:55553/api/

Authentication Failures

For MessagePack RPC, verify the username and password in your configuration file or CLI arguments. For JSON-RPC, verify the bearer token is valid and has not expired.

Database Not Available

If database-dependent tools return errors, ensure the database is running:

msfdb init
msfdb start

Then restart the MCP server.

Rate Limit Exceeded

Increase the rate limit in your configuration file:

rate_limit:
  requests_per_minute: 120
  burst_size: 20
